0.021mm single side aluminum PET mylar film Material for Flexible air ducts

Structure

Thickness(micron)

Weight(g/m2)

Yield(m2/kg)

AL7+PET12

22

38.7

25.8

AL7+PET19

29

48.6

20.6

AL7+PET40

50

78.0

12.8

AL9+ PET12

24

44.1

22.6

AL9 +PET15

27

48.4

20.7

AL9 +PET19

31

54.0

18.5

AL9 +PET23

35

59.6

16.8

AL9 +PET25

37

62.4

16.0

AL9+PET40

52

83.4

12.0

AL10 +PET25

38

65.1

15.4

AL12 +PET12

27

52.3

19.1

AL12 +PET15

30

56.5

17.7

AL12 +PET19

34

62.1

16.1

AL12 +PET23

38

67.7

14.8

AL12 +PET36

51

85.9

11.6

AL20+PET20

40

85.2

11.7

AL20+PET25

48

92.2

10.8

AL30+PET23

56

116.5

8.6

AL15 +PET19

37

70.2

14.2

AL25 +PET12

40

87.6

11.4

AL25 +PET23

52

104.0

9.6

AL25 +PET25

54

106.8

9.4

AL38+PET23

65

139.2

7.2

AL40 +PET12

56

129.2

7.7

AL40 +PET15

59

133.4

7.5

AL40 +PET23

67

144.6

6.9

AL40 +PET36

80

162.8

6.1

AL50 +PET12

66

156.3

6.4

AL50 +PET15

69

160.5

6.2

AL50 +PET23

77

171.7

5.8

AL50 +PET36

90

189.9

5.3

AL7+PET15+AL7

34

63.9

15.6

AL7+PET19+AL7

38

69.5

14.4

AL9+PET15+AL9

38

74.8

13.4

AL9+PET19+AL9

42

80.4

12.4

AL9+PET23+AL9

46

86.0

11.6

AL9+PET25+AL9

48

88.8

11.3

AL12+PET15+AL12

44

91.0

11.0

AL20+PET12+AL20

57

130.2

7.7

AL25+PET12+AL25

67

157.3

6.4

Type

ID

OD

Width

Core Material

PAD

53mm(2") 76mm(3")

Max. 650mm

5mm-1300mm

Paper core& plastic core

Spool

76mm(3")

Max. 500mm

Max. 400mm

Paper
